scm-setup

Source Control Server Preparation

Pre-requisite

1. ssh client (built-in on Windows 10. Preinstall with Git installation). For windows 7 alternative, try Putty
2. git

# use windows package manager
$ winget install Git.Git

3. TortoiseGit

# use windows package manager
$ winget install TortoiseGit.TortoiseGit

4. Tailscale

# use windows package manager
$ winget install tailscale.tailscale

---

Configuration

1. setup sshkey. Run below to generate the private / public key. SSH key-pair

$ ssh-keygen

2. Pass the c:\users\<username>\.ssh\id_rsa.pub to administrator to authorise the access to server (xxx.xxx.xxx.xxx)

# from ubuntu shell
$ ssh-copy-id -i ~/.ssh/id_rsa.pub mitpenang@xxx.xxx.xxx.xxx/home/mitpenang/.ssh/authorized_keys

# from powershell
PS c:> type $env:USERPROFILE\.ssh\id_rsa.pub | ssh mitpenang@xxx.xxx.xxx.xxx "cat >> .ssh/authorized_keys"

3. Setup Tailscale. Need remote access to administrator to do first login. Please install AnyDesk to facilitate remote access
4. Setup c:\Windows\System32\Drivers\etc\hosts file. Install PowerToys. Add the following entry to host file

127.0.0.1      dev.mitech.com.sg                                 # Test Eng Server

5. Setup git profile configuration

$ git config --global user.name "John Doe"
$ git config --global user.email johndoe@example.com

# setup default branch name as `main`
$ git config --global init.defaultBranch main

# Checking the settings
$ git config --list

---

Accessing the server

1. Establish ssh port forwarding. Open a command prompt. Run below command. The ssh IP address can be found from Tailscale console

$ ssh -L 3000:172.16.16.2:3000 -L 222:172.16.16.2:222 mitpenang@100.72.57.125

2. Open Chrome. Browse to Source Control Server Mitech : Gitea
3. To clone, use git ssh://...

---

Git

1. Documentation
2. GitHub Flow Branching Strategy
